Motorola GP series Detailed Service Manual

UHF2 PCB8485641Z06 Parts List 3-27
L302 2479990B01 11. 03 nH
L303 2462587V26 22nH, 5%
L304 2462587V37 180nH, 5%
L305 2462587V23 12nH, 5%
L306 2479990B01 11. 03 nH
L307 2479990B01 11. 03 nH
L309 2479990C02 16.28nH
L310 2462587V36 150nH, 5%
L311 2462587N65 750nH, 5%
L314 2462587N72 2200nH, 5%
L321 NOTPLACED -
L325 2480646Z20 2.2uH
L330 2462587N64 680nH, 5%
L331 2480646Z20 2.2uH
L332 2462587N53 100nH, 5%
L340 2462587V41 390nH
L400 2462587Q42 390nH
L401 2462587Q42 390nH
L410 2462587Q42 390nH
L411 2462587Q42 390nH
L505 2462587Q42 390nH
P100 3905643V01 Ground contact finger
PB501 4080523Z01 Tactile switch, pushbutton
PB502 4080523Z01 Tactile switch, pushbutton
PB503 4080523Z01 Tactile switch, pushbutton
PB504 4080523Z01 Tactile switch, pushbutton
PB505 4080523Z01 Tactile switch, pushbutton
Q110 4813828A09 RF Power Amplifier
Q111 4802245J50 Dual NPN/PNP transistor
Q210 4802245J50 Dual NPN/PNP transistor
Q241 4805218N63 RF NPN transistor
Q260 4802245J50 Dual NPN/PNP transistor
Q261 4802245J50 Dual NPN/PNP transistor
Q301 4802245J44 NPN Transistor
Q302 4802245J44 NPN Transistor
Q310 NOTPLACED -
Q315 4880214G02 NPN Transistor
Q316 NOTPLACED -
Q320 4805218N63 RF NPN transistor
Q400 4809579E18 Mosfet P - channel
Q403 4813824A17 Bipolar Transistor, PNP
Q405 4802245J54 Dual NPN Transistor
Q410 4802245J54 Dual NPN Transistor
Q416 4809579E18 Mosfet P - channel (not used in
GP640)
Q417 4802245J50 Dual NPN/PNP transistor
Q502 5180159R01 Dual NPN Transistor
Q505 4880214G02 NPN Transistor
R101 0662057A34 240
R102 0680539Z01 0.1
R104 0662057N15 47k
Circuit
Ref
Motorola
Part No.
Description
R106 0662057M26 10
R107 NOTPLACED -
R108 0662057M92 5600
R109 0662057N30 200k
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057N14 43k
R130 0662057M98 10k
R131 0662057N05 18k
R132 0662057N33 270k
R133 NOTPLACED -
R136 0662057N47 1M
R161 0662057M57 200
R170 0662057A34 240
R171 0662057N14 43k
R172 0662057A32 200
R173 0662057N29 180k
R174 0662057N15 47k
R175 0662057B59 3
R176 0662057B59 3
R191 0662057C01 0
R201 0662057N21 82k
R202 0662057N23 100k
R204 0662057N15 47k
R205 NOTPLACED -
R206 NOTPLACED -
R231 0662057M52 120
R232 0662057M69 620
R233 0662057M68 560
R241 0662057M32 18
R242 0662057M52 120
R243 0662057M98 10k
R244 0662057N03 15k
R245 0662057M59 240
R248 0662057M37 30
R251 0662057M38 33
R252 0662057M60 270
R253 0662057M95 7500
R254 0662057M96 8200
R255 0662057M89 4300
R256 0662057M37 30
R260 0662057M74 1000
R281 NOTPLACED -
R300 0662057M82 2200
R301 0662057N23 100k
R302 0662057N23 100k
R303 0662057M78 1500
R304 0662057N01 12k
R305 0662057M66 470
R306 0662057N23 100k
Circuit
Ref
Motorola
Part No.
Description
R307 0662057N23 100k
R308 0662057M60 270
R309 0662057M32 18
R310 0662057M60 270
R311 0662057N10 30k
R312 0662057M83 2400
R313 0662057M62 330
R314 0662057M85 3000
R315 0662057N01 12k
R316 0662057A96 91K
R317 0662057M74 1000
R318 0662057A79 18K
R319 0662057A29 150
R320 0662057M74 1000
R321 0662057M83 2400
R322 0662057N30 200k
R324 0662057M81 2000
R325 0662057M94 6800
R326 NOTPLACED -
R327 0662057N11 33k
R328 0662057M12 2.7
R329 0662057M01 0
R330 NOTPLACED -
R331 NOTPLACED -
R332 NOTPLACED -
R333 NOTPLACED -
R334 NOTPLACED -
R335 NOTPLACED -
R336 NOTPLACED -
R338 NOTPLACED -
R339 0662057M01 0
R340 0662057M96 8200
R342 0662057N23 100k
R343 0662057M26 10
R344 0662057N01 12k
R345 0662057M98 10k
R346 0662057N17 56k
R347 0662057M74 1000
R348 0662057M87 3600
R349 0662057C01 0
R350 0662057N23 100k
R351 0662057C01 0
R352 0662057M86 3300
R355 0662057M01 0
R400 0662057N15 47k
R401 0662057M01 0
R402 NOTPLACED -
R403 NOTPLACED -
R405 0662057M01 0
R406 0662057N20 75k
R407 0662057N19 68k
Circuit
Ref
Motorola
Part No.
Description
R408 NOTPLACED
R409 0662057M98 10k
R410 0662057N23 100k
R411 0662057M98 10k
R413 0662057M01 0
R414 0662057V34 180k, 1%
R415 0662057V26 91k, 1%
R416 0662057M98 10k
R418 0662057M01 0
R419 0662057M67 510
R420 0662057B46 10M (not used in GP640)
R421 0662057M81 2000
R423 0662057N39 470k
R424 0662057N12 36k
R425 0662057N10 30k
R426 0662057N35 330k (not used in GP640)
R427 0662057M84 2700
R428 0662057M10 2.2
R429 0662057M98 10k
R431 0662057N39 470k
R432 0662057N16 51k
R434 0662057M62 330
R435 0662057M81 2000
R436 0662057M01 0
R437 NOTPLACED -
R445 0662057N08 24k
R447 0662057N23 100k
R448 0662057M98 10k
R449 0662057N08 24k
R450 0683962T45 68 ohms, 1W
R451 0662057N03 15k
R452 0662057N23 100k
R453 NOTPLACED -
R454 NOTPLACED -
R455 NOTPLACED -
R456 0662057M01 0
R457 0662057M98 10k
R460 0662057M90 4700
R461 0662057M56 180 (not used in GP640)
R462 0662057M98 10k (not used in GP640)
R463 0662057M61 300
R471 0662057N06 20k
R472 0662057N12 36k
R473 0662057M26 10
R475 0662057M01 0
R476 0662057N08 24k
R477 0662057M74 1000
R478 0662057M98 10k
R481 0662057N08 24k
R492 0662057M01 0
R501 0662057M70 680
Circuit
Ref
Motorola
Part No.
Description

Motorola GP series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Number of Channels	16
Channel Spacing	12.5 kHz / 25 kHz
Battery Life	8 hours (with standard battery)
Operating Voltage	7.5V DC
Ingress Protection	IP54
MIL-STD	810 C, D, E, F
