Motorola GP series Detailed Service Manual

3-40 UHF2 PCB 8485677Z03 (GP1280) Parts List
R104 0662057N15 47K
R106 0662057M26 10
R107 NOTPLACED
R108 0662057M92 5.6K
R109 0662057N30 200K
R110 0662057M61 300
R111 0662057M33 20
R112 0662057M61 300
R120 0662057N14 43K
R130 0662057M98 10K
R131 0662057N05 18K
R132 0662057N33 270K
R133 NOTPLACED
R136 NOTPLACED
R161 0662057M57 200
R170 0662057A34 240
R171 0662057N14 43K
R172 0662057A32 200
R173 0662057N29 180K
R174 0662057N15 47K
R175 0662057B59 3
R176 0662057B59 3
R191 0662057C01 0
R201 0662057N21 82K
R202 0662057N23 100K
R204 0662057N15 47K
R205 NOTPLACED
R206 NOTPLACED
R231 0662057M52 120
R232 0662057M69 620
R233 0662057M68 560
R241 0662057M32 18
R242 0662057M52 120
R243 0662057M98 10K
R244 0662057N03 15K
R245 0662057M59 240
R248 0662057M37 30
R251 0662057M38 33
Circuit
Ref.
Motorola
Part No.
Description
R252 0662057M60 270
R253 0662057M95 7.5K
R254 0662057M96 8.2K
R255 0662057M89 4.3K
R256 0662057M37 30
R260 0662057M74 1K
R281 NOTPLACED
R300 0662057M82 2.2K
R301 0662057N23 100K
R302 0662057N23 100K
R303 0662057M78 1.5K
R304 0662057N01 12K
R305 0662057M66 470
R306 0662057N23 100K
R307 0662057N23 100K
R308 0662057M60 270
R309 0662057M32 18
R310 0662057M60 270
R311 0662057N10 30K
R312 0662057M83 2.4K
R313 0662057M62 330
R314 0662057M85 3K
R315 0662057N01 12K
R316 0662057A96 91K
R317 0662057M74 1K
R318 0662057A79 18K
R319 0662057A29 150
R320 0662057M74 1K
R321 0662057M83 2.4K
R322 0662057N30 200K
R324 0662057M81 2K
R325 0662057M94 6.8K
R326 NOTPLACED
R327 0662057N11 33K
R328 0662057M12 2.7
R329 0662057M01 0
R330 NOTPLACED
R331 NOTPLACED
Circuit
Ref.
Motorola
Part No.
Description
R332 NOTPLACED
R333 NOTPLACED
R334 NOTPLACED
R335 NOTPLACED
R336 NOTPLACED
R338 NOTPLACED
R339 0662057M01 0
R340 0662057M96 8.2K
R342 0662057N23 100K
R343 0662057M26 10
R344 0662057N01 12K
R345 0662057M98 10K
R346 0662057N17 56K
R347 0662057M74 1K
R348 0662057M87 3.6K
R349 0662057C01 0
R350 0662057N23 100K
R351 0662057C01 0
R352 0662057M86 3.3K
R355 0662057M01 0
R400 0662057N15 47K
R401 0662057M01 0
R402 NOTPLACED
R403 NOTPLACED
R405 0662057M01 0
R406 0662057N20 75K
R407 0662057N19 68K
R408 NOTPLACED
R409 0662057M98 10K
R410 0662057N23 100K
R411 0662057M98 10K
R413 0662057M01 0
R414 0662057V34 180K
R415 0662057V26 91K
R416 0662057M98 10K
R418 0662057M01 0
R419 0662057M67 510
R420 0662057B46 10M
Circuit
Ref.
Motorola
Part No.
Description
R421 0662057M81 2K
R423 0662057N39 470K
R424 0662057N12 36K
R425 0662057N10 30K
R426 0662057N35 330K
R427 0662057M84 2.7K
R428 0662057M10 2.2
R429 0662057M98 10K
R431 0662057N39 470K
R432 0662057N16 51K
R434 0662057M62 330
R435 0662057M81 2K
R436 0662057M95 7500
R437 NOTPLACED
R445 0662057N08 24K
R447 0662057N23 100K
R448 0662057M98 10K
R449 0662057N08 24K
R450 0683962T45 68
R451 0662057N03 15K
R452 0662057N23 100K
R453 NOTPLACED
R454 NOTPLACED
R455 NOTPLACED
R456 0662057M01 0
R457 0662057M98 10K
R460 0662057M90 4.7K
R461 0662057M56 180
R462 0662057M98 10K
R463 0662057M61 300
R471 0662057N06 20K
R472 0662057N12 36K
R473 0662057M26 10
R475 0662057M01 0
R476 0662057N35 330K
R477 0662057M74 1K
R478 0662057M98 10K
R481 0662057N08 24K
Circuit
Ref.
Motorola
Part No.
Description
