3-72 UHF2 PCB 8415235H01 & 8415235H05 Schematics (EPP)
C108
390nH
100pF
1
L105
SH100
SHIELD
HF SHIELD
ANT_BIAS
CR101
L102
12.39nH
12.39nH
L101
RF_JACK
C104
7.5pF
C103
13pF7.5pF
C101
100pF
C102
3.3pF
C107C106
4.7pF
2
3
1
CR102
RX_IN
R170
240
R101
240
36pF
C188
TX_OUT
L104
12.39nH
UHF2 (450-527MHz) Harmonic Filter (PCB 8415235H05)
