Motorola GP series

3-80 UHF2 PCB 8415235H05 Parts List
C231 2113946K02 CAP CER CHP 0.10UF 16V
C232 2113945D02 CAP CER CHP 47,000PF
25V 10%
C233 2313960A26 CAP TANT 0.1 UF 10% 35V
3216-18
C234 2313960A55 CAP TANT 0.47 UF 10%
25V 3216-18
C235 2113946N03 CAP CER CHP 2.2UF 16V
C238 2113945L17 CAP,FXD,470PF,+5%,-
5%,50V-DC,0603,
C241 2113944A40 CAP CER CHP 100.0PF
50V 5%
C242 2113944A16 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C243 2113944A16 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C244 2113944C17 CAP CER CHP 3.0PF 50V
+/- 0.25PF
C245 2113944A11 CAP CER CHP 2.7PF 50V
+/- 0.25PF
C246 2113944A40 CAP CER CHP 100.0PF
50V 5%
C247 2113944A40 CAP CER CHP 100.0PF
50V 5%
C248 2113946K02 CAP CER CHP 0.10UF 16V
C250 2113944A16 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C251 2113944A40 CAP CER CHP 100.0PF
50V 5%
C252 2113944A18 CAP CER CHP 5.1PF 50V
+/- 0.5PF
C253 2113944C12 CAP CER CHP 1.8PF 50V
+/- 0.25PF
C254 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C255 2113944A40 CAP CER CHP 100.0PF
50V 5%
Circuit
Ref
Motorola
Part No.
Description
C256 2113944A18 CAP CER CHP 5.1PF 50V
+/- 0.5PF
C257 2113944A40 CAP CER CHP 100.0PF
50V 5%
C258 2113945B02 CAP CER CHP 10,000PF
25V 10%
C259 2113945B02 CAP CER CHP 10,000PF
25V 10%
C260 2113944A40 CAP CER CHP 100.0PF
50V 5%
C263 2113944A62 CAP,FXD,.75PF,.25PF+/-
,50V-DC,040
C264 2113944A40 CAP CER CHP 100.0PF
50V 5%
C265 NOT-
PLACED
-
C271 NOT-
PLACED
-
C272 2115153H01 CAP, CERAMIC, COG
C273 2113946K02 CAP CER CHP 0.10UF 16V
C276 2113946N03 CAP CER CHP 2.2UF 16V
C277 2113944A40 CAP CER CHP 100.0PF
50V 5%
C278 2313960D07 CAP TANT 10 UF 10% 16V
3528-21
C279 2113946N03 CAP CER CHP 2.2UF 16V
C281 2113944A40 CAP CER CHP 100.0PF
50V 5%
C282 NOT-
PLACED
-
C283 NOT-
PLACED
-
C285 2113944A40 CAP CER CHP 100.0PF
50V 5%
C286 2113946K02 CAP CER CHP 0.10UF 16V
Circuit
Ref
Motorola
Part No.
Description
C289 2113944A40 CAP CER CHP 100.0PF
50V 5%
C291 2313960M5
1
CAP TANT 10 UF 10% 6.3V
2012-12
C292 2113946K02 CAP CER CHP 0.10UF 16V
C293 2113945G98 CAP,FXD,.47UF,+10%,-
10%,50V-DC,080
C294 2113944A40 CAP CER CHP 100.0PF
50V 5%
C295 2113944A40 CAP CER CHP 100.0PF
50V 5%
C296 2113946K02 CAP CER CHP 0.10UF 16V
C297 2113945B02 CAP CER CHP 10,000PF
25V 10%
C298 2113946K02 CAP CER CHP 0.10UF 16V
C301 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C302 2113944A26 CAP CER CHP 12.0PF 50V
5%
C303 2113944C21 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C304 2113944A77 CAP,FXD,11PF,+5%,-
5%,50V-DC,0402,C
C305 2113944A40 CAP CER CHP 100.0PF
50V 5%
C306 NOT-
PLACED
-
C307 2113944A40 CAP CER CHP 100.0PF
50V 5%
C308 2113944A40 CAP CER CHP 100.0PF
50V 5%
C309 2113944A40 CAP CER CHP 100.0PF
50V 5%
C310 2113944A40 CAP CER CHP 100.0PF
50V 5%
C311 NOT-
PLACED
-
Circuit
Ref
Motorola
Part No.
Description
C312 2113944A22 CAP CER CHP 7.5PF 50V
+/- 0.5PF
C313 2113944A77 CAP,FXD,11PF,+5%,-
5%,50V-DC,0402,C
C314 2113946K02 CAP CER CHP 0.10UF 16V
C315 2113944A40 CAP CER CHP 100.0PF
50V 5%
C316 2113944C21 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C317 2113944A73 CAP,FXD,8PF,.5PF+/-,50V-
DC,0402,C
C318 2113944A26 CAP CER CHP 12.0PF 50V
5%
C319 2113944A16 CAP CER CHP 4.3PF 50V
+/- 0.25PF
C320 2113944A24 CAP CER CHP 9.1PF 50V
+/- 0.5PF
C321 2113944A40 CAP CER CHP 100.0PF
50V 5%
C322 2113944A38 CAP CER CHP 82.0PF 50V
5%
C324 2115153H40 CAP, CERAMIC, COG
C325 2115153H26 CAP, CERAMIC, COG
C326 2113946K02 CAP CER CHP 0.10UF 16V
C327 2113946K02 CAP CER CHP 0.10UF 16V
C328 2113946K02 CAP CER CHP 0.10UF 16V
C329 2113946K02 CAP CER CHP 0.10UF 16V
C334 2113945A13 CAP CER CHP 4700PF
50V 10%
C337 NOT-
PLACED
-
C338 NOT-
PLACED
-
C343 2113946K02 CAP CER CHP 0.10UF 16V
C344 2113945D04 CAP CER CHP 100,000PF
25V 10%
Circuit
Ref
Motorola
Part No.
Description
