Motorola GP series - Page 435

UHF2 PCB 8415235H05 Parts List 3-83
CR160 NOT-
PLACED
-
CR201 4815011H01 DIODE,SWG,300MA,80V
CR203 4815072H01 DIODE,VCTR,1SV232,30V
CR241 4885094Y01 DIODE VARACTOR ISV228
W18
CR242 4885055Y01 DIODE VARACTOR PB-
FREE
CR243 4885055Y01 DIODE VARACTOR PB-
FREE
CR251 4815322H01 VHF VARIABLE CAPACI-
TANCE DIODE
CR301 4885055Y01 DIODE VARACTOR PB-
FREE
CR302 4885055Y01 DIODE VARACTOR PB-
FREE
CR303 4815048H01 DIODE,SHTK,MMBD353LT
1,SM,7V
CR304 4885055Y01 DIODE VARACTOR PB-
FREE
CR305 4885055Y01 DIODE VARACTOR PB-
FREE
CR306 4802245J42 RING QUAD DIODE SOT-
143 PKG
CR311 4813974A19 DIODE SCHOTTKY BAR-
RIER SERIES
CR312 4815047H01 DIODE,SWG,DAN235EFTL
,35V
CR313 4815047H01 DIODE,SWG,DAN235EFTL
,35V
CR411 4815067H01 DIODE
ARRAY,SWG,RB731UFT10
8,SMD,1M
CR412 4815067H01 DIODE
ARRAY,SWG,RB731UFT10
8,SMD,1M
Circuit
Ref
Motorola
Part No.
Description
CR413 4815067H01 DIODE
ARRAY,SWG,RB731UFT10
8,SMD,1M
CR440 4813978C02 PB FREE, NOT COM-
PLETELY ENRICHED
CR501 4815155H01 RECTIFIER
CR503 4805729G49 DIODE RED/YEL
D601 4880479U01 LED
D602 4880479U01 LED
D603 4880479U01 LED
D604 4880479U01 LED
D605 4880479U01 LED
D606 4880479U01 LED
E101 2415954H01 INDUCTOR BEAD CHIP
E102 7686949J14 FLTR, FERRITE BEAD,,,,
2A,,,,, SM, 0805
E105 7686949J14 FLTR, FERRITE BEAD,,,,
2A,,,,, SM, 0805,, CHIP,
220OHM
E400 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E401 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E402 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E403 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E404 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E405 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E406 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E407 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
Circuit
Ref
Motorola
Part No.
Description
E408 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E409 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E634 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E637 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E638 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E639 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E640 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E641 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E642 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E643 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E644 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E645 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
F501 6515076H01 FUSE,FST
BLW,3A,24V,FUSE CHIP
SMT T
FL201 4805875Z04 CRYSTAL 16.8 MHZ
FL301 9180022M11 XTAL FILTER 44.85MHZ
FL302 9180468V04 SMD455KHZ 4 ELEMENT
CER FLTR
FL303 9115811H03 SMD455KHZ 6 ELEMENT
FL304 9115811H01 SMD455KHZ 6 ELEMENT
FL401 4870368G02 REFLOWABLE CLOCK
OSC XTAL
H101 2680499Z02 HEAT SPREADER
Circuit
Ref
Motorola
Part No.
Description
J101 0985613Z01 JACK,RF
J102 0280519Z02 NUT, ANTENNA
J400 0915064H03 CONNECTOR, ZIF (40
PINS)
J403 0915064H02 CONN,CONN,F,20CONT,C
ONNECTOR, ZIF
J601 0980521Z03 CONN, ZIF VERTICAL,
40PINS
J602 0915064H01 CONN,CONN,F,18CONT,C
ONNECTOR, ZIF
L101 2460591B28 COIL AIR WOUND INDUC
13.37
L102 2460591B28 COIL AIR WOUND INDUC
13.37
L104 2460591B48 COIL AIR WOUND INDUC
15.22
L105 2462587N22 CHIP IND 390 NH 10%
L106 2460591A19 COIL AIR WOUND INDUC
8.71
L107 2479990G01 AIR WOUND COIL/GREEN
COLOR 33.47NH
L108 2479990A01 AIR WOUND COIL/GREEN
COLOR 4.22NH
L112 2462587N42 CHIP IND 12 NH 5%
L113 2414017H09 IND CHIP 5.6 NH +/- 0.3NH
L114 2462587N42 CHIP IND 12 NH 5%
L115 2462587N22 CHIP IND 390 NH 10%
L116 2479990C02 AIR WOUND COIL/GREEN
COLOR 16.28NH
L117 2414017P17 IND CER CHIP 22.0 NH 5%
L160 2414017H14 IND CHIP 15.0 NH 5%
L201 2462587Q20 IND CHIP 2,200NH 20%
L202 2462587Q20 IND CHIP 2,200NH 20%
L203 2462587Q20 IND CHIP 2,200NH 20%
Circuit
Ref
Motorola
Part No.
Description
