Motorola GP328 Detailed Service Manual

6B-2 Model Chart
GP Series, VHF, 136-174 MHz
Model Description
AZH25KDC9AA3 with
option AZQ203AD
GP328 136-174 MHz 5W (w/o keypad, camouflage)
AZH25KDC9AA3 with
option AZH64AG
GP328 136-174 MHz 5W (w/o keypad, yellow)
AZH25KDH9AA6 with
option AZQ203AF
GP338 136-174 MHz 5W (keypad, camouflage)
AZH25KDH9AA6 with
option AZH64AI
GP338 136-174 MHz 5W (keypad, yellow)
Item Description
X PMUD1804_ GP328 Super Tanapa 136-174 MHz 5W
X PMUD1800_ GP328 Super Tanapa 136-174 MHz 5W
X PMUD1806_ GP338 Super Tanapa 136-174 MHz 5W
X PMUD1802_ GP338 Super Tanapa 136-174 MHz 5W
X PMUD1805_ GP328 Tanapa 136-174 MHz 5W
X PMUD1801_ GP328 Tanapa 136-174 MHz 5W
X PMUD1807_ GP338 Tanapa 136-174 MHz 5W
X PMUD1803_ GP338 Tanapa 136-174 MHz 5W
X X PMLD4109_ GP328 B/C Kit 136-174 MHz 5W
X X PMLD4110_ GP338 B/C Kit 136-174 MHz 5W
X PMLN4539_ GP328 Front Housing Kit
X PMLN4544_ GP328 Front Housing Kit
X PMLN4538_ GP338 Front Housing Kit
X PMLN4545_ GP338 Front Housing Kit
X X X X PMAD4012_ Antenna, 136-155 MHz Stubby
XXXXPMAD4013_ Antenna,155-174MHzStubby
X X X X PMAD4014_ Antenna, 136-155 MHz 14 cm
XXXXPMAD4015_ Antenna,155-174MHz14cm
X X X X PMAD4023_ Antenna, 150-164 MHz 14 cm
XXXXPMAD4025_ Antenna,150-161MHzStubby
X X X X NAD6579_ Antenna, 148-161 MHz 19 cm
X X 6804110J54 GP328 User Guide
X X 6804110J55 GP338 User Guide
x = Indicates one of each is required.

Motorola GP328 Specifications

General

Channel Capacity	16 channels
Operating Temperature	-30°C to +60°C
Sealing	IP54
Frequency Range	136-174 MHz (VHF), 403-470 MHz (UHF)
Power Output	1-5W (VHF), 1-4W (UHF)
Dimensions	137 x 57.5 x 37.5 mm
Power Supply	7.5V
Battery Life	8 hours (High Power), 11 hours (Low Power) with standard NiMH battery
Weight	420g (with standard battery)
