Motorola GP328 Detailed Service Manual

6B-1
Section 6B
MODEL CHART AND TEST SPECIFICATIONS (136-174
MHZ)
1.0 Model Chart
GP Series, VHF, 136-174 MHz
Model Description
AZH25KDC9AA2 GP328 136-174 MHz 5W 4CH
AZH25KDC9AA3 GP328 136-174 MHz 5W
AZH25KDH9AA6 GP338 136-174 MHz 5W
Item Description
X PMUD1573_ GP328 Super Tanapa 136-174 MHz 5W 4CH
X PMUD1480_ GP328 Super Tanapa 136-174 MHz 5W
X PMUD1481_ GP338 Super Tanapa 136-174 MHz 5W
X PMUD1574_ GP328 Tanapa 136-174 MHz 5W 4CH
X PMUD1495_ GP328 Tanapa 136-174 MHz 5W
X PMUD1496_ GP338 Tanapa 136-174 MHz 5W
X PMLD4159_ GP328 B/C Kit 136-174 MHz 5W 4CH
X PMLD4109_ GP328 B/C Kit 136-174 MHz 5W
X PMLD4110_ GP338 B/C Kit 136-174 MHz 5W
X PMLN4348_ GP328 Front Housing Kit 4CH
X PMLN4216_ GP328 Front Housing Kit
X PMLN4199_ GP338 Front Housing Kit
XXXPMAD4012_ Antenna,136-155MHzStubby
X X X PMAD4013_ Antenna, 155-174 MHz Stubby
XXXPMAD4014_ Antenna,136-155MHz14cm
X X X PMAD4015_ Antenna, 155-174 MHz 14 cm
XXXPMAD4023_ Antenna,150-164MHz14cm
X X X PMAD4025_ Antenna, 150-161 MHz Stubby
XXXNAD6579_ Antenna,148-161MHz19cm
X X 6804110J54 GP328 User Guide
X 6804110J55 GP338 User Guide
x = Indicates one of each is required.

Motorola GP328 Specifications

General

Channel Capacity	16 channels
Operating Temperature	-30°C to +60°C
Sealing	IP54
Frequency Range	136-174 MHz (VHF), 403-470 MHz (UHF)
Power Output	1-5W (VHF), 1-4W (UHF)
Dimensions	137 x 57.5 x 37.5 mm
Power Supply	7.5V
Battery Life	8 hours (High Power), 11 hours (Low Power) with standard NiMH battery
Weight	420g (with standard battery)
