6B-38 Circuit Board/Schematic Diagrams and Parts List
C4020 2113743L17 1000pF, 10%
C4021 2113743L17 1000pF, 10%
C403 2113743G24 2.2uF, +/-80%/-20%
C407 2113928N01 0.1uF, 10%
C408 2113743N50 100pF
C409 2113928N01 0.1uF, 10%
C410 2113928N01 0.1uF, 10%
C411 2113928N01 0.1uF, 10%
C414 2113928N01 0.1uF, 10%
C415 2185895Z01 0.01uF, 10%
C416 2113928N01 0.1uF, 10%
C419 2113743L41 10000pF, 10%
C420 2113743L41 10000pF, 10%
C421 2113928N01 0.1uF, 10%
C422 2113928N01 0.1uF, 10%
C423 2113743N50 100pF
C424 2311049A59 10uF,10%,6V
C425 2113928N01 0.1uF, 10%
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113928N01 0.1uF, 10%
C429 2113928N01 0.1uF, 10%
C430 2113928N01 0.1uF, 10%
C431 2113743N50 100pF
C433 2113743L41 10000pF, 10%
C434 2113928N01 0.1uF, 10% (not placed in
GP328)
C435 2113928N01 0.1uF, 10%
C436 2113743N34 22pF (not placed in GP328)
C437 2113743N34 22pF (not placed in GP328)
C440 2113743G26 4.7F, + 80/-20%
C441 2113743L09 470pF, 10%
C442 2113743E20 0.10uF, 10%
C443 2113928N01 0.1uF, 10%
C444 2113743N50 100pF
C445 2113743L09 470pF, 10%
C446 2113743L09 470pF, 10%
C447 2113928N01 0.1uF, 10%
C448 2113928N01 0.1uF, 10%
C449 2113743N50 100pF
C451 2113743M08 22000pF, +80/-20%
C452 2113743B29 1uF
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
C467 2113928N01 0.1uF, 10%
C471 2113743L09 470pF, 10%
C472 2113743L09 470pF, 10%
Circuit
Ref
Motorola
Part No.
Description
C473 2113743L09 470pF, 10%
C474 2113743L41 10000pF, 10%
C475 2113743H14 10uF, +80/-20%
C476 2113928D08 10uF, +/-80%/-20%
C477 2113743L17 1000pF, 10%
C478 2113743L17 1000pF, 10%
C479 2113928N01 0.1uF, 10%
C480 2113928D08 10uF, +/-80%/-20%
C481 2113928N01 0.1uF, 10%
C482 2113928N01 0.1uF, 10%
C483 2113743L09 470pF, 10%
C484 2113743L09 470pF, 10%
C490 2113743L09 470pF, 10%
C491 2113743L09 470pF, 10%
C492 2113743L09 470pF, 10%
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743L09 470pF, 10%
C496 2113743L09 470pF, 10%
C497 2113743L09 470pF, 10%
C502 2311049A05 0.47uF, 10%, 25V
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 10000pF, 10%
C521 2113743L41 10000pF, 10%
C522 2113743L41 10000pF, 10%
C523 2113743L41 10000pF, 10%
C535 2113743L17 1000pF, 10%
CR3301 4802245J42 Ring Quad diode
CR3302 4805129M96 Dual Bonds Pin Diode, RH
Reeled
CR3303 4880154K03 Dual common anode-cathode
diode
CR411 4802245J62 Schottky diode
CR412 4802245J62 Schottky diode
CR413 4802245J62 Schottky diode
CR440 4813833C02 Dual Diode Common Cathode
CR501 4880107R01 Rectifier
CR503 4805729G49 LED Red/Yellow
D3270 4862824C01 Varactor
D3301 4802081B58 Dual Diode
D3302 4802081B58 Dual Diode
D3521 4880973Z02 Pin diode
D3551 4880973Z02 Pin diode
D3701 4802233J09 Triple diode
D3702 4802233J09 Triple diode
D3761 4862824C03 Varactor
Circuit
Ref
Motorola
Part No.
Description
D3821 4805649Q13 Varactor
D3831 4805649Q13 Varactor
D3832 4862824C01 Varactor
E400 2480640Z01 Ferrite bead
E401 2480640Z01 Ferrite bead
E402 2480640Z01 Ferrite bead
E403 2480640Z01 Ferrite bead
E404 2480640Z01 Ferrite bead
E405 2480640Z01 Ferrite bead
E406 2480640Z01 Ferrite bead
E407 2480640Z01 Ferrite bead
E408 2480640Z01 Ferrite bead
E409 2480640Z01 Ferrite bead
F501 6580542Z01 3A Fuse
FL401 4870368G02 Real Time Clock Oscialltor
XTAL (not placed in GP328)
H3501 2680499Z01 Heat spreader
J3501 0985613Z01 RF Jack
J3502 0280519Z02 Antenna_Nut
J400 0905505Y04 40-pin connector
J403 0905505Y02 20-pin connector
L3200 2462587N68 1uH
L3202 2462587N68 1uH
L3221 2462587N68 1uH
L3270 2462587T15 100nH
L3271 2462587Q20 2.2uF
L3301 2462587T35 12nH
L3303 2462587T35 12nH
L3304 2462587T23 470nH
L3305 2462587T35 12nH
L3306 2462587T35 12nH
L3308 2462587T34 10nH
L3309 2462587N55 150nH
L3312 2462587V28 33nH
L3501 2413926H09 5.6nH
L3503 2462587V32 68nH
L3504 2462587N51 68nH
L3511 2462587N44 18nH
L3512 2479990B01 11.03nH
L3513 2479990A02 7.66nH, 10%
L3515 2479990C03 13.85nH
L3519 2484657R01 Ferrite bead
L3521 2479990A02 7.66nH, 10%
L3522 2479990E01 23.75nH
L3523 2462587N68 1uH
L3531 2479990N01 43.67nH
L3532 2479990N01 43.67nH
L3538 2479990M01 30.54nH
L3551 2479990N01 43.67nH
L3552 2479990A02 7.66nH, 10%
L3701 2462587Q42 390nH, 10%
Circuit
Ref
Motorola
Part No.
Description
L3731 2462587Q20 2.2uF
L3801 2462587V34 100nH
L3809 2462587V27 27nH
L3811 2462587V34 100nH
L3812 2462587V34 100nH
L3813 2462587Q47 1000nH, 10%, QF45
L3816 2462587V34 100nH
L3821 2462587N50 56nH
L3822 2462587N49 47nH
L3823 2462587N49 47nH
L3824 2462587N68 1uH
L3825 2462587V34 100nH
L3826 2462587N68 1uH
L3831 2462587N50 56nH
L3832 2462587N51 68nH
L3833 2462587N50 56nH
L3834 2462587N68 1uH
L400 2462587Q42 390nH, 10%
L401 2462587Q42 390nH, 10%
L410 2462587Q42 390nH, 10%
L411 2462587Q42 390nH, 10%
L505 2462587Q42 390nH, 10%
PB501 4080523Z01 Tactile, Pushbutton
PB502 4080523Z01 Tactile, Pushbutton
PB503 4080523Z01 Tactile, Pushbutton
PB504 4080523Z01 Tactile, Pushbutton
PB505 4080523Z01 Tactile, Pushbutton
Q3200 4813827A07 NPN Transistor
Q3201 4880214G02 NPN Transistor
Q3202 4880214G02 NPN Transistor
Q3270 4805218N63 RF Transistor
Q3301 4880214G02 NPN Transistor
Q3302 4813827A07 NPN Transistor
Q3501 4813828A08 FET
Q3561 4813824A17 PNP Transistor
Q3721 4802245J50 Dual NPN/PNP Transistor
Q3801 4813827A07 NPN Transistor
Q400 4809579E18 Mosfet P - channel
Q403 4813824A17 PNP Transistor
Q405 4802245J54 Dual NPN Transistor
Q410 4802245J54 Dual NPN Transistor
Q416 4809579E18 Mosfet P - channel (not placed
in GP328)
Q417 4802245J50 Dual NPN/PNP Transistor
Q502 5180159R01 Dual NPN Transistor
Q505 4880214G02 NPN Transistor
R3200 0662057M54 150
R3201 0662057M82 2200
R3202 0662057M90 4700
R3203 0662057M98 10k
R3204 0662057M26 10
Circuit
Ref
Motorola
Part No.
Description
