6B-40 Circuit Board/Schematic Diagrams and Parts List
* Motorola Depot Servicing only
VR439 4880140L17 Zener diode-12V
VR447 4802245J74 ZENER DIODE-10V
VR448 4802245J74 ZENER DIODE-10V
VR449 4802245J74 ZENER DIODE-10V
VR450 4802245J74 ZENER DIODE-10V
VR460 4802245J73 ZENER DIODE-6.8V
VR501 4802245J73 ZENER DIODE-6.8V
VR506 4802245J73 ZENER DIODE-6.8V
Y3200 9186153B01 Crystal Filter
Y3761 4805875Z04 16.8MHz Xtal oscillator (SMD)
5480678Z01 PCB Bar Code Label
8486062B16 VHF main PC Board
Circuit
Ref
Motorola
Part No.
Description
