6C-22 Circuit Board/Schematic Diagrams and Parts List
C401 2113743M24 0.1uF, +80%/-20%
C402 2113743M24 0.1uF, +80%/-20%
C403 2113743G24 2.2uF, +80%/-20%
C407 2113928N01 0.1uF, 10%
C408 2113743N50 100pF
C409 2113743M24 0.1uF, +80%/-20%
C410 2113928N01 0.1uF, 10%
C411 2113743M24 0.1uF, +80%/-20%
C414 2113743M24 0.1uF, +80%/-20%
C415 2109720D01 .01uF, 10%
C416 2113928N01 0.1uF, 10%
C419 Not Placed
C420 2113743L41 .01uF, 10%
C421 2113928N01 0.1uF, 10%
C422 2113743M24 0.1uF, +80%/-20%
C423 2113743N50 100pF
C424 2311049A59 10uF,10%;6V
C425 2113743M24 0.1uF, +80%/-20%
C426 2113743N50 100pF
C427 2113743N50 100pF
C428 2113743M24 0.1uF, +80%/-20%
C429 2113743M24 0.1uF, +80%/-20%
C430 2113928N01 0.1uF, 10%
C431 2113743N50 100pF
C432 Not Placed
C433 2113743L41 .01uF, 10%
C434 2113743M24 0.1uF, +80%/-20%
notusedinGP328
C435 2113743M24 0.1uF, +80%/-20%
C436 2113743N34 22pF
notusedinGP328
C437 2113743N34 22pF
notusedinGP328
C440 2113743G26 4.7uF, +80%/-20%
C441 2113743N50 100pF
C442 2113743E20 0.1uF, 10%
C443 2113928N01 0.1uF, 10%
C444 2113743N50 100pF
C445 2113743N50 100pF
C447 2113743M08 0.22uF, 10%
C448 2113928N01 0.1uF, 10%
C449 2113743N50 100pF
C450 2113743M24 0.1uF, +80%/-20%
C451 2113743M08 .022uF, +80%/-20%
C452 2113743G26 4.7uF, +80%/-20%
C453 2113743N50 100pF
C456 2113743N50 100pF
C458 2113743N50 100pF
C459 2113743N50 100pF
C463 2113743N50 100pF
C466 2113743N50 100pF
Circuit
Ref
Motorola
Part No.
Description
C467 2113928N01 0.1uF, 10%
C471 2113743LN50 100pF
C472 2113743L09 470pF
C473 2113743L09 470pF
C475 2113743H14 10uF, +80%/-20%
C476 2113928D08 10uF, +80%/-20%
C479 2113928N01 0.1uF, 10%
C480 2113928D08 10uF, +80%/-20%
C481 2113928N01 0.1uF, 10%
C482 2113928N01 0.1uF, 10%
C490 2113743N50 100pF
C491 2113743N50 100pF
C492 2113743N50 100pF
C493 2113743N50 100pF
C494 2113743N50 100pF
C495 2113743N50 100pF
C496 2113743N50 100pF
C497 2113743N50 100pF
C502 2311049A05 0.47uF, 10%; 25V
C503 2113743N50 100pF
C505 2113743N50 100pF
C511 2113743N50 100pF
C512 2113743N50 100pF
C513 2113743N50 100pF
C514 2113743N50 100pF
C520 2113743L41 .01uF, 10%
C521 2113743L41 .01uF, 10%
C522 2113743L41 .01uF, 10%
C523 2113743L41 .01uF, 10%
CR101 4880973Z02 Pin Diode
CR102 4802245J41 Pin Diode
CR105 5185963A15 Temperature Sense
CR201 4802233J09 Triple Diode
CR203 4862824C03 Varactor
CR241 4805649Q13 Dual Varactor
CR242 4862824C01 Varactor
CR243 4862824C01 Varactor
CR251 4862824C01 Varactor
CR301 4862824C01 Varactor
CR302 4862824C01 Varactor
CR303 4880154K03 Dual Common Anode-Cath-
ode
CR304 4862824C01 Varactor
CR305 4862824C01 Varactor
CR306 4802245J42 Ring Quad Diode
CR308 4802245J41 Pin Diode
CR310 4862824C01 Varactor
CR411 4802245J47 Schottky Diode
CR412 4802245J47 Schottky Diode
CR413 4802245J47 Schottky Diode
CR440 4813833C02 Dual Diode Common Cathode
Circuit
Ref
Motorola
Part No.
Description
CR501 4880107R01 Rectifier
CR503 4805729G49 LED Red/Yel
D401 4802245J62 Diode Schottky, RB731U
D402 4802245J62 Diode Schottky, RB731U
D403 4802245J62 Diode Schottky, RB731U
E101 2484657R01 Ferrite Bead
E400 2480640Z01 Ferrite Bead
E401 2480640Z01 Ferrite Bead
E402 2480640Z01 Ferrite Bead
E403 2480640Z01 Ferrite Bead
E404 2480640Z01 Ferrite Bead
E405 2480640Z01 Ferrite Bead
E406 2480640Z01 Ferrite Bead
E407 2480640Z01 Ferrite Bead
E408 2480640Z01 Ferrite Bead
E409 2480640Z01 Ferrite Bead
F501 6580542Z01 Fuse 3A
FL201 4805875Z04 16.8MHz Xtal (SMD)
FL301 4802245J43 Xtal Filter 45.1MHz
FL401 4870368G02 Osc Xtal 38.4kHz
not used in GP328
H101 2680499Z01 Heat Spreader
J101 0180117S05 RF Jack Assembly
J102 0280519Z02 Antenna Nut
J400 0905505Y04 40-pins Connector
J403 0905505Y02 20-pins Connector
L101 2460591B24 12.39nH, 10%
L102 2460591B24 12.39nH, 10%
L104 2460591B24 12.39nH, 10%
L105 2462587N22 390nH, 10%
L106 2460591A11 7.66nH, 10%
L107 2460591G24 33.47nH, 10%
L108 2460591A01 4.22nH, 10%
L109 2460591B04 11.03nH, 10%
L112 2462587N22 390nH, 10%
L113 2413926H09 5.6nH, 5%
L114 2462587N22 390nH, 10%
L115 2462587N22 390nH, 10%
L116 2460591A50 9.75nH, 10%
L160 2413926H14 15.0nH, 5%
L201 2462587Q20 2.2uH, 20%
L202 2462587Q20 2.2uH, 20%
L203 2462587Q20 2.2uH, 20%
L232 2462587P25 12uH, 5%
L241 2462587V41 390nH, 10%
L242 2462587V26 22nH, 5%
L243 2460593C03 Teflon Resonator
L251 2462587V41 390nH, 5%
L253 2460593C03 Teflon Resonator
L261 2462587V29 39nH, 5%
L271 2462587V27 27nH, 5%
Circuit
Ref
Motorola
Part No.
Description
L273 2462587V25 18nH, 5%
L281 2462587V41 390nH, 10%
L282 2462587V41 390nH, 10%
L301 2460591B04 11.03nH, 10%
L302 2460591B04 11.03nH, 10%
L303 2462587V26 22nH, 5%
L304 2462587V37 180nH, 5%
L305 2462587V23 12nH, 5%
L306 2460591B04 11.03nH, 10%
L307 2460591B04 11.03nH, 10%
L309 2460591C16 16.28nH, 10%
L310 2462587V36 150nH,5%
L311 2462587N65 750nH,5%
L314 2462587N72 2.2uH, 5%
L321 Not Placed
L325 2480646Z20 2.2uH
L330 2462587N64 680nH, 5%
L331 2480646Z20 2.2uH
L332 2462587N53 100nH, 5%
L340 2462587V41 390nH, 10%
L400 2462587Q42 390nH, 10%
L401 2462587Q42 390nH, 10%
L410 2462587Q42 390nH, 10%
L411 2462587Q42 390nH, 10%
L505 2462587Q42 390nH, 10%
P100 3905643V01 Gnd Contact Finger
PB501 4080523Z01 Tactile, Pushbutton
PB502 4080523Z01 Tactile, Pushbutton
PB503 4080523Z01 Tactile, Pushbutton
PB504 4080523Z01 Tactile, Pushbutton
PB505 4080523Z01 Tactile, Pushbutton
Q110 4802245J55 RF Power FET
Q111 4802245J50 Dual NPN/PNP
Q210 4802245J50 Dual NPN/PNP
Q241 4805218N63 NPN
Q260 4802245J50 Dual NPN/PNP
Q261 4802245J50 Dual NPN/PNP
Q301 4802245J44 NPN
Q302 4802245J44 NPN
Q310 Not Placed
Q315 4880214G02 NPN
Q316 Not Placed
Q320 4805218N63 NPN
Q400 4809579E18 MOSFET P-Chan
Q403 4880214G02 NPN
Q405 4802245J54 Dual NPN
Q410 4802245J54 Dual NPN
Q416 4809579E18 MOSFET P-Chan
notusedinGP328
Q417 4802245J50 Dual NPN/PNP
Q502 5180159R01 Dual NPN
Circuit
Ref
Motorola
Part No.
Description
