Motorola GP328 Detailed Service Manual

6D-32 Circuit Board/Schematic Diagrams and Parts List
330-400MHz Radio Parts List
Circuit
Ref
Motorola
Part No.
Description
B501 0986237A02 Battery Contact Module
B503 3980502Z01 Backup Battery Contact, B+
( not used in GP328)
B504 3980501Z01 Backup Battery Contact, B-
( not used in GP328)
C101 2113740F51 100pF
C102 2113740F27 10pF
C103 2113740F32 16pF
C104 2113740F27 10pF
C105 2113743L05 330pF
C106 2113740F19 4.7pF
C107 2113740F15 3.3pF
C108 2113743L05 330pF
C109 2113740F51 100pF
C110 2113743L05 330pF
C111 2103689A46 22pF
C112 2180605Z34 56pF, high Q
C113 2180605Z16 10pF, high Q
C114 2113743L05 330pF
C115 NOT PLACED
C116 NOT PLACED
C117 2113743N36 27pF
C118 2113743N50 100pF
C119 2113743L05 330pF
C120 2113743N25 9.1pF
C121 2113743N50 100pF
C122 2113743L05 330pF
C123 2311049A18 10uF, 16V
C125 2113743N50 100pF
C126 2113743M24 100000pF
C127 2113743L17 1000pF
C128 2113743M08 22000pF
C129 2113743N33 20pF
C130 2113743L05 330pF
C131 2113743M08 22000pF
C132 2113743L05 330pF
C133 2113743L17 1000pF
C134 2113743L29 3300pF
C135 2113743M08 22000pF
C138 2113743L05 330pF
C140 NOT PLACED
C141 NOT PLACED
C150 2113743M08 22000pF
C151 2113743L05 330pF
C152 2113743M08 22000pF
C160 2113743N50 100pF
C161 2113743M24 100000pF
C165 2113743N50 100pF
C166 2113743L05 330pF
C169 2113743N30 15pF
C170 2113743L05 330pF
C171 2113743L05 330pF
C172 2113743E20 0.1uF
C173 2113743M08 22000pF
C174 2113743L05 330pF
C180 NOT PLACED
C181 NOT PLACED
C188 2113743N50 100pF
C193 2113743M24 100000pF
C201 2113743N50 100pF
C202 2113743L17 1000pF
C203 2311049A56 4.7uF, 10V
C204 2104993J02 2.2uF
C206 2113740F63 330pF
C207 2113743N40 39pF
C208 NOT PLACED
C210 2113743N50 100pF
C211 2113743N50 100pF
C212 2113743N50 100pF
C213 2113743N50 100pF
C214 2113743N50 100pF
C215 NOT PLACED
C216 NOT PLACED
C217 2104993J02 2.2uF
C218 2113743M24 100000pF
C219 2113743K16 0.22uF
C220 2113743N50 100pF
C223 2113743M24 100000pF
C224 2113743M24 100000pF
C228 2311049J11 4.7uF, 16V
C229 2113743L17 1000pF
C230 2113743N50 100pF
C231 2113743M24 100000pF
C232 2113743E12 0.047uF
C233 2311049A01 0.1uF, 35V
C234 2311049A05 0.47uF, 25V
C235 2104993J02 2.2uF
C238 2113741F17 470pF
C241 2113743N50 100pF
C242 2113743N23 7.5pF
C243 2113743N22 6.8pF
C244 2113740F13 2.7pF
C245 2113743N12 2.7pF
C246 2113743N50 100pF
C247 2113743N50 100pF
C248 2113743M24 100000pF
C250 2113743N23 7.5pF
C251 2113743N50 100pF
C252 2113743N29 13pF
C253 NOT PLACED
Circuit
Ref
Motorola
Part No.
Description
C254 2113743N12 2.7pF
C255 2113743N50 100pF
C256 2113743N29 13pF
C257 2113743N50 100pF
C258 2113743L41 10000pF
C259 2113743L41 10000pF
C260 2113743N50 100pF
C263 NOT PLACED
C264 2113743N50 100pF
C265 NOT PLACED
C271 2113743N03 1pF
C272 2113743N03 1pF
C273 2113743M24 100000pF
C276 2104993J02 2.2uF
C277 2113743N50 100pF
C278 2311049A57 10uF
C279 2104993J02 2.2uF
C281 2113743N50 100pF
C282 NOT PLACED
C283 NOT PLACED
C285 2113743N50 100pF
C286 2113743M24 100000pF
C289 2113743N50 100pF
C291 2311049A69 10uF, 6.3V
C292 2113743M24 100000pF
C293 2113743A27 0.47uF
C294 2113743N50 100pF
C295 2113743N50 100pF
C296 2113743M24 100000pF
C297 2113743L41 10000pF
C298 2113743M24 100000pF
C301 2113743N24 8.2pF
C302 2113743N28 12pF
C303 2113740L11 5.1pF
C304 2113743N27 11pF
C305 2113743N28 12pF
C306 2113743N22 6.8pF
C307 2113743M24 100000pF
C308 2113743N50 100pF
C309 2113743N50 100pF
C310 2113743M24 100000pF
C311 NOT PLACED
C312 2113743N24 8.2pF
C313 2113743N27 11pF
C314 2113743M24 100000pF
C315 2113743N50 100pF
C316 2113740L11 5.1pF
C317 2113743N27 11pF
C318 2113743N24 8.2pF
C319 2113743N21 6.2pF
C320 2113743N20 5.6pF
Circuit
Ref
Motorola
Part No.
Description
C321 2113743N50 100pF
C322 2113743N48 82pF
C323 2113743N54 150pF
C324 2113743N33 20pF
C325 2113743L41 10000pF
C326 2113743L41 10000pF
C327 2113743N50 100pF
C328 2113743M24 100000pF
C329 2113743M24 100000pF
C330 2113743N26 10pF
C331 2113743N50 100pF
C333 NOT PLACED
C334 2113743M08 22000pF
C336 2113743M24 100000pF
C337 2113743N50 100pF
C338 2113743N30 15pF
C339 2180478Z20 1uF
C340 2180478Z20 1uF
C341 2180478Z20 1uF
C342 2180478Z20 1uF
C343 2113743A23 0.22uF
C344 2113743M24 100000pF
C345 2113743M24 100000pF
C346 2113743M24 100000pF
C347 2113743M24 100000pF
C348 2113743M24 100000pF
C349 2113743E07 0.022uF
C350 2113743L05 330pF
C351 2113743N33 20pF
C352 2113743N28 12pF
C353 2113743N41 43pF
C354 2113743N42 47pF
C355 2113743A24 0.33uF
C356 2113743M08 22000pF
C357 2113743A23 0.22uF
C358 2113741A23 1200pF
C359 2109720D14 0.1uF, low distortion
C360 2113743E07 0.022uF
C361 2113741F49 10000pF
C362 2113743M08 22000pF
C363 2311049A40 2.2uF, 10V
C364 2113743L41 10000pF
C370 2113743N50 100pF
C371 NOT PLACED
C372 NOT PLACED
C373 NOT PLACED
C374 2113743N50 100pF
C375 2113743N50 100pF
C378 NOT PLACED
C380 2113743L41 10000pF
C381 NOT PLACED
Circuit
Ref
Motorola
Part No.
Description
