4-4 Controller Board
ModB/Vstby Supply
Under various conditions, the supply to the ModB/Vstby would vary. Table 4-1 shows these
conditions and circuits in operation.
Table 4-1: ModB/Vstby Supply Modes
Condition Circuit Operation
Radio On Vdd supply voltage via CR411
Radio Off Vdd turned off
Q416 gate is pulled low by R462
Q416 is switched on
U410 supplies 3.2V to ModB/Vstby
Primary battery removed Vdd turned off
Q416 gate is pulled low by R462
Q416 is switched on
LiO battery provides 3.2V to ModB/Vstby
Flash Mode Boot_Ctrl line pull low
ModA & ModB goes low
Processor in boot-strap mode
Flashing enabled
