Mechanical Views and Parts Lists 3-21
* Not field serviceable
Item
Motorola
Part
Number
Description
1 See Chapter
6
Antenna
2 JMLN4638_ Dust Cover
3 1385905Z01 Universal Connector Seal
4 0302020P03 Screw for Dust Cover
5 3385959Z07 Front, label GP344
6 6102001P10 Light Pipe
7 0104031G98 Front Cover Assembly
8 3680530Z02 Frequency Knob
9 3680529Z01 Volume Knob
10 1302012P06 Top Plastic Plate
11 3385906Z01 Top Sheet
12 3202000P15 Top Seal Rubber
13 3502416P03 Speaker Mesh
14* Part of Item 7 PTT Rubber
15* Part of Item 7 PTT Plastic Cover
16 5005679X01 Speaker
17 1480577C01 Boot Microphone
18 8404079G01 Flex PCB Universal
19* 8404051G07 Controller Board
20 0385913Z01 4 M2x4 Philips Screws
21 0302020P05 1 M2x1 Philips Screw
22 8404078G01 Flex PCB RF Controller
23* 8404055G05 RF Board (VHF)
8404077G01 RF Board (UHF)
8485641Z02 RF Board (UHF 2)
24 3280534Z01 Seal Contact
25 3202000P14 O-ring
26 1502001P31 Chassis
To Next Page
