Mechanical Views and Parts Lists 3-23
Item
Motorola
Part
Number
Description
1 See Chapter 6 Antenna
2 3680529Z01 Volume Knob
3 3680530Z02 Frequency Knob
4 1386160Z01 Top Escutcheon
5 3385906Z01 Escutcheon Label
6 3286159Z01 Control Top Seal
7 6186158Z01 Lightpipe
8 1386091Z01 PTT Bezel
9 7586090Z01 PTT Rubber
10 3386098Z05 Nameplate GP388
11 1586088Z01 Front Cover Assembly
12 1385905Z01 Escutcheon, Universal
Connector
13 Dust Cover, Universal
Connector
14 7580540Z01 LCD Front Pad
15 5104949J11 LCD Module
16 7586096Z01 Main Keypad
17 4086199Z01 Keypad Polydome
18 8404056G01 Controller Board
19 8404078G01 Flex RF Controller
20 3586092Z01 Speaker Felt
21 1480577C01 Microphone Boot
22 5013920A04 Microphone
23 5086094Z01 Speaker
24 8486095Z01 Flex, Universal
Connector
25 4286097Z01 Keypad Retainer
26 0386104Z01 Screw
27 1480503Z01 Backup Battery Boot
28 6080656Z01 Battery Backup
29 8404055G05 RF Board (VHF)
8404077G01 RF Board (UHF)
30 7580556Z01 Thermal Pad
31 3280534Z01 Battery Module Seal
32 1485673Z01 Antenna Nut Insulator
33 3285892Z01 Main O-Ring
34 2786154Z01 Chassis
Item
Motorola
Part
Number
Description
To Next Page
