Motorola GP600 Series User Manual

Mechanical View and Parts List 3-15
Item
Motorola
Part
Number
Description
1 See Chapter 6 Antenna
2 3680529Z01 Knob, Volume
3 3680530Z01 Knob, Frequency
4 1380525Z01 Escutcheon, Top
5 3380644Z01 Escutcheon, Label
6 3280533Z01 Seal, Control Top
7 6180527Z01 Litepipe, Tx
8 1364279B06 Front, label
9 1586059A01 Dust Cover, Universal
Connector
10 1386058A01 Escutcheon, Universal Flex
11 1580666Z03 Front Cover, Basic
12 Not Field
Replaceable
Escutcheon, FM
13 7580532Z01 Keypad, Side Control
14 1380528Z01 Bezel, Side Control
15 7580620Z03
7580620Z04
Keypad, Blank
Keypad, Full
16 0104007J99 Keypad Board Assembly
17 4280498Z01 Retainer, Keypad PCB
18 3586057A01 Felt Speaker
19 1480577C01 Boot, Microphone
20 5085962A02 Speaker
21 5013920A04 Microphone
22 8480549Z01 Flex, UC
23 2113740A41 Capacitor, 33pF
24 4280504Z01 Retainer, Speaker
25 0304726J04 Screw
26 See Chapter 6 Back Cover Kit incl. chassis
main board
27 8480475Z02 Flex, Keypad/Controller
28 1480652Z01 Insulator, Antenna
29 7580556Z01 Pad, Thermal
30 3280534Z01 Seal, Contact
31 3280536Z01 Gasket, o-Ring
32 3980698Z01 Contact, Ground, Compliant,
VHF
33 2780518Z01 Chassis
34 See Chapter 6 Battery
35 HLN9714A Beltclip
Item
Motorola
Part
Number
Description
