RADIO OVERVIEW
On/Off/Volume Knob
Turns the radio on or off, and adjusts the
radio’s volume.
Channel or Zone/Menu Selector Knob
Switches the radio to different conventional or
trunked zones. Also, can be used for scrolling
between conventional channels or trunked
talkgroups.
LED Indicator
Indicates status of battery, power-up, scan,
and receipt of a channel, talkgroup, or a
selective call (see table below):
Side Connector
Used for connecting accessories, such as
headsets and remote speaker/microphones, to
the radio.
Replace the attached side connector cover
when the connector is not in use.
Programmable Buttons
Several of your radio’s buttons can be
programmed by your dealer as shortcut
buttons for many of the radio’s features.
Programmable buttons include:
• The three Side Buttons (A, B, C) and the
Top Button (D)
• The three lower Menu Keys (P1, P2, P3)
(when the radio is not in menu mode)
LED Color Indicates
Steady red Radio is transmitting (PTT button
pressed)
Flashing red Radio is attempting to access
trunked system (PTT button
pressed), or
Radio is receiving (PTT button
released)
Single
flashing yellow
Call Light feature
Double
flashing yellow
Selective call received (LTR only)
Momentary
green
Radio has powered-up
successfully
Single
flashing green
System or All Group Scan
operation, PassPort Group Scan
LED Color Indicates
