Motorola MBP24 User Manual

10
Getting Started
2.2 Parent unit battery installation
The rechargeable battery pack supplied should be installed so that
the Parent Unit can be moved without losing the link with the Baby
Unit. Charge the parent unit before using it for the first time and
when the parent unit indicates the battery is low.
• Open and lift the battery door up as shown in the figure. (fig.b1)
(Fig.b1)
(Fig.b2)
(Fig.b3)
• Insert the plug of the rechargeable battery pack into the jack
inside, fit the battery pack into the compartment. (fig.b2)
(Fig.b1)
(Fig.b2)
(Fig.b3)
• Insert the catches at the top of the battery door then close the
door as shown in the picture. (fig.b3)
(Fig.b1)
(Fig.b2)
(Fig.b3)
NOTE
Only use the power adapter provided (DC6/400mA).
We recommend that you install and fully charge the battery in the
parent unit, so that it continues to work if you disconnect it from the
mains power to carry it to another location.

Motorola MBP24 Specifications

General

Night-light	-
Display type	LCD
Product color	White
Volume control	Buttons
Backlight color	Orange
Built-in display	Yes
Maximum range	- m
Frequency range	1881.792 - 1897.344 MHz
Channels quantity	10 channels
Operating temperature (T-T)	10 - 40 °C
Battery voltage	2.4 V
AC input voltage	100-240 V
Battery capacity	750 mAh
AC input frequency	50 - 60 Hz
Battery technology	Nickel-Metal Hydride (NiMH)
Receiver power source	AC
Transmitter power source	Battery
