Number Description
13 Laptop
NOTICE: The junction box PCB is not repairable. Order a new junction box as necessary.
4.6.5
Installing Junction Box
The junction box can be installed horizontally and vertically. The junction box has no connector sealing
and is designed for use in dust and water protected location only. See the following figure.
Procedure:
1 Secure the data junction box GMLN5089_ with the four screws supplied with kit.
2 Connect the connection cable PMKN4101_ (length = 6 m), PMKN4102_ (length = 4 m) or
PMKN4103_ (length = 2 m) from the junction box to the accessory connector on the rear side of
the transceiver and fasten it with the plug-screws.
The cable used for installation purposes only must be ordered separately. Ingress Protection
(IP) Code: IP30
3 All other devices should be adapted as shown in the preceding figure.
4.6.6
Connecting Accessories to the Junction Box
Procedure:
1 Connect all accessories to the junction box. If required see “Re-crimp Procedure” to be able to
connect your accessory.
2 Connect the mobile-terminal-to-Junction box cable to the junction box.
3 Connect the programming cable to the junction box (if required).
68015000181-LB
Chapter 4: Radio Installation
