Detailed Features/Benefits Description 2-7
3.2.3 LED Indicator
The LED Indicator is conveniently located on the top of the radio, making it easy for the user to see
at all times, even when the radio is being worn on a belt.
The LED Indicator provides instant visual feedback to the user regarding power-up, power level,
transmit/receive state, scanning and battery state.
Different modes of LED Indicator operation can be selected using the CPS to provide different types
of information. The information provided by the different LED Indicator modes is summarised below:
Normal Operation :
Tx Power Operation:
As above except when the radio is transmitting, the following operation occurs to indicate whether
high or low power is selected:
Tx Battery Operation:
As above except when the radio is transmitting, the following operation occurs to provide detailed
information about the battery charge state:
Table 2-6 Normal Operation
LED State/Colour Indication
Power Up
Temporary continuous GREEN
Radio performing self test
TX/RX
Continuous RED
Blinking RED
Radio Transmitting
Radio receiving carrier
Scan*
Blinking GREEN
Scan Active
Low Battery
Blinking RED while transmitting Low Battery Level
Table 2-7 Tx Power Operation
LED State/Colour Indication
TX/R
Continuous RED High Power
Continuous GREEN Low Power
Table 2-8 Tx Battery Operation
LED State/Colour Indication
TX/RX
Flashing GREEN Battery is fully charged
Continuous GREEN Optimal battery charge level
To Next Page
