Motorola P100 Series Quick Reference Guide

4
English
Keypad
Lock
Locks or unlocks all
buttons except PTT,
Side Programmable
Button 1, Side
Programmable
Button 2 and ON/
OFF/Volume Knob.
Applicable for Long
Press only.
Nuisance
Channel
Delete
Removes unwanted
channel(s)
temporarily from
scan list during Scan.
Applicable for Long
Press only.
Phone
Mode
Enables or disables
Phone feature for the
selected channel.
TPL/DPL
Enable
Enables or disables
radio from requiring
matching TPL/DPL
to unsquelch.
Prime
Channel
Enables quick move
to the selected Prime
Channel.
Button Function
PTT ID
Enable
Enables or disables
PTT ID sent on PTT
press.
Reverse
Burst
Selects the Reverse
Burst Type: None,
180 or 240.
Scrambling
Code
Select
Toggles between the
two scrambling
codes available.
Scrambling
Enable/
Disable
Enables or disables
Voice Inversion
Scrambling feature
for the selected
channel. Applicable
for Long Press only.
Squelch
Level
Selects desired
squelch level:
Normal or Tight.
Unassigned No function is
programmed to this
button.
VOX Enables or disables
VOX feature for the
selected channel.
Button Function
Sticky
Monitor
Toggles the
permanent monitor
function until button
is pressed again.
Applicable for Long
Press only.
Talkaround/
Repeater
Mode
Enables toggle
between repeater
and talkaround mode
operations.
Volume Set Controls audio level.
Button emits
continuous tone to
indicate current
volume level. To
change volume level,
turn volume knob to
desired level while
pressing
programmable
button. Applicable for
Long Press only.
Button Function
6878276A01-B EMEA QRG.book Page 4 Thursday, September 23, 2010 6:31 PM
