Motorola P100 Series Quick Reference Guide

5
English
LCD Icons Display
LCD
Indicator
Description Function
Signal
Strength
More bars
indicate a
stronger
signal.
Talkaround Radio not
transmitting
through
repeater.
Power
Level
“L”
indicates
that radio is
transmitting
in low
power; “H”
indicates
that radio is
transmitting
in high
power.
Monitor Radio is
monitoring
a selected
channel.
Voice
Inversion
Scrambling
Illuminates
when
Scrambling
Mode is
ON.
Phone
Mode
Illuminates
when
Phone
Mode is
selected.
Prog. Mode Illuminates
when Prog.
Mode is
ON.
Keypad
Lock
Illuminates
when
keypad is
locked.
LCD
Indicator
Description Function
Battery
Level
Shows
remaining
charge in
battery by
number of
bars
(0 – 3).
Blinks
when the
battery is
low.
Scan Blinks
without dot
when
normal
Scan is
activated.
Illuminates
without dot
when there
is some
activity on
a non-
priority
channel.
LCD
Indicator
Description Function
