Label Item Description
7 Push-to-Talk (PTT) button Allows you to press and hold down this
button to talk, and release it to listen.
8 Side button 1 (SB1) A general button that is configurable
using the Customer Programming Soft-
ware (CPS).
NOTE: The default setting of
SB1 is Monitor.
9 Side button 2 (SB2) A general button that is configurable
using the CPS.
NOTE: The default setting of
SB2 is Scroll Down to the
desired channel.
10 Battery All RM Series radios come with a Lithi-
um-Ion (Li-Ion) battery.
2.1
LED Indicators
Table 5: Radio LED Indicators
Radio Status LED Indication
Channel Busy Solid orange
Cloning Mode Double blinking orange
Cloning in Progress Solid orange
Fatal Error at Power Up Alternating green, orange, and green for four seconds
Low Battery Blinking orange
Low Battery Shutdown Rapid blinking orange
Monitor LED is off
Power Up Solid red for two seconds
Idle Programming Mode /Chan-
nel Mode
Blinking green
Scan Mode Rapid blinking red
Transmit (Tx)/Receive (Rx) Solid red
Transmit in Low Power Select Solid orange
VOX/iVOX Mode Double blinking red
68012009071-BD
Chapter 2: Radio Overview
12
