Hardware
Motorola, Inc.
570510-001-00 rev A
Page 18 of 50
DC power connector (used during in
stallation, not under normal
operation)
RJ11 filtered phone port
Eth1 – 10/100 auto-sensing Ethernet
Eth2 – 10/100 auto-sensing Ethernet
RJ11 line-in port (not shown, acce
ssible when
bracket is
removed)
17
19
