System Administration
Motorola, Inc. 570510-001-00 rev A Page 21 of 50
H
H
T
T
T
T
P
P
M
M
e
e
n
n
u
u
s
s
Monitor Menu
Quick access to all Ethernet, DSL and Wireless interface status and statistics
Color coded Port Monitor:
Green - Ethernet Port or DSL Port is operating normally and within tolerance
Gray - Ethernet Port is enabled, but disconnected.
Yellow - Indicates an alert condition.
Red – Indicates a warning or alert condition. When applied to the Line Status, Red
indicates the line is enabled, but the WallPlate is disconnected.
Black – Port is disabled
System Menu
All configuration items related to setting up the system and management access. For
example; IP address, SNMP, image upgrade
Interface Menu
Configure all Ethernet, DSL and Wireless interfaces. Note: the wireless commands under
the Interface menu are global commands that apply to all WLANs on a single radio.
Wifi Menu
Configure WLANs. Create up to 20 profiles. Each profile contains unique parameters
including SSID, DTIM, Broadcast SSID, Isolation, Timeout, and Security
Advanced Menu
Advanced configurations including 802.1Q VLANs, IGMP, QoS
