Motorola XTS-5000 - Battery Management

Universal Connector CoverUniversal Connector Cover
The universal connector cover
p
rotects the side
On / Off / Volume
Ctl
p
connector near the antenna.
To remove the cover:
1
Turn the radio off
2
3
C
on
t
ro
l
1
1
.
Turn
the
radio
off
.
2. Carefully insert a flat-bladed screwdriver between the
bottom of the cover and the connector.
3
Holding the top of the cover with your thumb push
2
3
.
Holding
the
top
of
the
cover
with
your
thumb
,
push
the screwdriver gently downward and lever the cover
away from the radio.
To install the cover:
2
1. Turn the radio off.
2. Insert the hooked end of the cover into the slot above
the connector.
3
2121
3. Rub the ball of your thumb from the top to the bottom
of the cover, applying pressure towards the radio. This
will flex the cover and snap it into place.
