Motorola XTS Series User Manual

3
REFERENCE MOTOROLA
SYMBOL PART NO. DESCRIPTION
Electrical Parts List
COIL, RF: unless stated
L1,2 2462575A04 Choke, 1µH
L3 thru 6 2462587Q44 Choke, 0.56µH
LS1 5005213W01 SPEAKER: 1 3/4"; 28½
MK1 5005227J06 MICROPHONE: Electret
SWITCH:
S1 3905834K07 Dome, PTT
S2 4005680K04 Toggle
VR1, 2 4880140L14 DIODE: Zener, 9.1V (See Note)
C1
0.1µF
R2 150
R1 150
C2
.022µF
C3
82pF
C4
330pF
VR1
9.1V
MK1
PTT
S1
MICROPHONE HEAD
L2
1µH
J2
4
3
5
2
1
L6
560nH
L4
C6
1pF
C5
560pF
L3
COAX
COAX
BLK BLK
GND
WHT WHT
GND
EXT ANT
PTT
EXTERNAL
L1
1µH
EXT MIC
MIC
CORD
GRN
GRN
LS1
BLU
BLU
SIDE
VIEW
OF
RADIO
CONNECTOR
RED
RED
SPKR
SPKR
1
RF
GND
3
5
7
9
11
2
2
L5
0.56nH
0.56nH
0.56nH
6
3
1
8
4
6
8
10
12
13
S2
1
2
3
HI
LO
J1
MAEPF-25767-O
5
CAPACITOR, Fixed: pF±5%; 63V
unless stated
C1 2113741B69 0.1µF
C2 2184008H19 .022µF
C3 2113740A53 82
C4 2113740A67 330
C5 2113740A73 560
C6 2113740A03 1
JACK:
J1 0905100W01 Micro, 3.5mm
J2 - - - - - - - - - - Mechanical parts; items 2, 3, 5, 6,
8, 9, and 10 on exploded view
J3 0905830Z01 Connector, Coaxial SMT
Note: For optimum performance, order replacement diodes by Motorola part
number only.
J3
