Moultrie Mobile DELTA - KEY COMPONENTS OF THE DELTA CELLULAR TRIAL CAMERA

UPPER CABLE LOCK
ATTACHMENT POINT
CAMERA STRAP
ATTACHMENT POINT
CONTROL PANEL/
SD CARD INSERT
(LOCATED INSIDE DOOR LATCH)
LOWER CABLE LOCK
ATTACHMENT POINT
1/4-20 TRIPOD MOUNTING PORT
& MOUNTING SUPPORTS
11
12
13
14
15
12
ANTENNA
AIM LED
AMBIENT LIGHT SENSOR
940 NM HIGH POWER IR LED
LENS AND IMAGE SENSOR
PIR SENSOR
CABLE LOCK ATTACHMENT POINT
DOOR LATCH WITH CABLE LOCK
ATTACHMENT POINT
12V EXTERNAL POWER JACK INPUT
MICROPHONE
1
2
3
4
5
6
7
8
9
10
KEY COMPONENTS OF THE DELTA CELLULAR TRIAL CAMERA
D1
