Mount-It! MI-2752 - Step 3 Attach the VESA Plate to the Monitor; Step 4 Slide the Monitor onto the Head of Swivel Arm

Attach the VESA Plate to the Monitor
5
s
r
h
q
Step 3
Slide the Monitor onto the Head of Swivel Arm
Step 4
For Monitor with Flat Back For Monitor with Curved or
Recessed Back
Slide the monitor onto the head of
Swivel Arm(d) as shown in the above
diagram.
Install the security Nut(h). Make sure the
security nut is installed before you rotate
the monitor.
