INSTALLATION CONSIDERATIONS
WARNING: Please read and follow these installation considerations before beginning the
installation to ensure the wall mount is compatible with your mounting location and display.
1. The temperature at the front of the fireplace mantle must never exceed 100°F (38°C).
2. If mounting to studs, the studs must be spaced no more than 24” (609mm) apart.
These studs should be symmetrically positioned, or the installation will not be even.
The drywall must be no more than 5/8” thick.
≤
12"
From 65”~85”
Weight:
61~110lbs
(28~50kg)
5
3.
The distance from the mesa of the fireplace to the wall must be less than 12 ″(30.4cm).
STUDS
100°F Max
