Mountain Top EVOe - Automatic Calibration; Manual Emergency Release; Reconnect Drive Mechanism

880 909 / Issue 02
3.5 - Auto Calibration
To calibrate / reset the EVOe roll cover, and
press and hold the button on the remote for
12 seconds.
During calibration, the roll cover will open com-
pletely, then close. The lights will slowly fade on
and off.
12 sec.
Calibration should be done monthly.
3.6 - Emergency Release
A release handle is located on the right side of the
rear prole. Pull the handle down to disengage the
motor and belt drive.
The EVOe roll cover can then be operated manually.
3.7 - Reconnect after Emergency Release
To reconnect the motor and belt drive after an
emergency release, press the rear prole rmly
into the belt drive handles.
2 audible “CLICKS” should come from both drive
handles.
After reconnecting, ensure the drive handles
are properly connected to the belt drive on both
sides.
Ensure that the GREEN tab is in the middle of
GREEN YELLOW
the YELLOW clip.
07/25
