UPRIGHT BICYCLE
-01 Electronic Module - 01 Chassis in metallic tube- 01 Fairing fixed to the chassis - 02 Feet
with 02 levelers each, 01 being loose and 01 fixed to the chassis- 02 Sail-feet - 01 Magnetic
brake set inserted in the fairing and fixed to the chassis- 01 split support column for the
electronic module, with rubberized handlebars and 02 sensors for heart rate - 01 saddle with
vertical column- 01 vertical support column for the saddle and adjustment key- 05 screws-
01 Allen key- 01 Spanner no. 16- 02 Pedals (WARNING !!! The pedals are not the same, 01
corresponds to the right side - letter R (right) at the end of the screw -, another to the left side
- letter L (left) at the end of the screw).
1
Description of the parts contained in the packaging (vertical bicycle)
A
A1
A
A1
2
A fixação em ordem inversa, poderá danificar a rosca de fixação tanto do pedal
quanto do pé-de-vel
Remove the equipment from the box and
arrange the loose parts to identify them.
Fit the support column tube
A to point A1.
Fixing in reverse order may damage the fixing thread of both the pedal and the pedestal.
