7
8
9
B
B1
6
Fit the vertical column of
the Saddle B to the
support column B1.
Adjust the height of the saddle
according to the user, pulling
the adjustment key to be able to
slide the column up or down to
the desired height of the
saddle, and then release the
button. Turn the knob clockwise
to give the final tightening.
Fix the pedals (right onR
the right crank, left on theL
left crank) with the spanner
no. 16.
Check all fittings and screw
settings.
Congratulations, your equipment is
ready to use. Good training !
