70 SPECIFICATIONS
Connecting the Chassis
1. Make sure the handlebar is secured in an
upright position (see Figure 54).
Figure 54
Place the back chassis vertically. Hold the front
chassis by the handlebar and bring it toward the
back chassis (see Figure 55).
Figure 55
2. Bring the two parts together and use the
hanging hooks (see Figure 56) to align the two
ends properly. At this point the central release
button will click.
Figure 56
To Next Page
