Moxa Technologies MGate MB3270 Quick Installation Guide

- 6 -
Optical Fiber Interface
100BaseFX
Multi-mode
Single-mode
Fiber Cable Type OM1
50/125 μm
G.652
800 MHz*km
Typical Distance
4 km
5 km
40 km
Wave-
length
Typical (nm)
1300
1310
TX Range (nm)
1260 to 1360
1280 to 1340
RX Range (nm)
1100 to 1600
1100 to 1600
Optical
Power
TX Range (dBm)
-10 to -20
0 to -5
RX Range (dBm)
-3 to -32
-3 to -34
Link Budget (dB)
12
29
Dispersion Penalty (dB)
3
1
Note: When connecting a single-mode fiber transceiver, we recommend
using an attenuator to prevent damage caused by excessive optical
power.
Note: Compute the “typical distance” of a specific fiber transceiver as
follows: Link budget (dB) > dispersion penalty (dB) + total link loss (dB).
Specifications
Power Requirements
Power Input
12 to 48 VDC
Power Consumption
(Input Rating)
• MGate MB3170, MGate MB3170-T, MGate
MB3270, MGate MB3270-T:
12 to 48 VDC, 435 mA (max.)
• MGate MB3270I, MGate MB3270I-T, MGate
MB3170-M-ST, MGate MB3170-M-ST-T,
MGate MB3170-M-SC, MGate
MB3170-M-SC-T:
12 to 48 VDC, 510 mA (max.)
• MGate MB3170I, MGate MB3170I-T, MGate
MB3170-S-SC, MGate MB3170-S-SC-T,
MGate MB3170I-S-SC, MGate
MB3170I-S-SC-T, MGate MB3170I-M-SC,
MGate MB3170I-M-SC-T:
12 to 48 VDC, 555 mA (max.)
Operating
Temperature
0 to 60°C (32 to 140°F),
-40 to 75°C (-40 to 167°F) for –T model
Storage Temperature
-40 to 85°C (-40 to 185°F)
Operating Humidity
5 to 95% RH
Magnetic Isolation
Protection (serial)
2 kV (for “I” models)
Dimensions
Without ears:
With ears extended:
29 x 89.2 x 118.5 mm (1.14 x 3.51 x 4.67 in)
29 x 89.2 x 124.5 mm (1.14 x 3.51 x 4.9 in)
Relay Output 1 digital relay output to alarm (normal close):
current carrying capacity 1 A @ 30 VDC
Hazardous Location
UL/cUL Class 1 Division 2 Group A/B/C/D, ATEX
Zone 2, IECEx
