GECKO OWNERS MANUAL
Version 3 7
2. Remove the rear leading edge tubes which are packed separately in the same box. Remove
the packaging.
3. Expose the leading edge/cross bar junction through the inspection zipper. Remove the
packaging from the end of the front leading edges.
4. Get the rear leading edge tubes and identify the left and right sides by the color of the
sticker. LEFT is RED, RIGHT is GREEN. Lay the leading edges on the ground in the
approximate place along the wing where they will go. The dive strut cable must be on the
top of the leading edge and the dive strut must fold towards the rear.
5. On the sail wing tip, open the zip. Take the rear leading edge and slide it inside the sail. As
you proceed, rotate the dive strut forward and hold against the leading edge so it can slide
in past the cloth rib.
