GECKO OWNERS MANUAL
Version 3 8
6. Push the rear leading edge into the front leading edge. Continue to slide the back section
in until the slot locates the clevis pin in the front section. If the back section is located
properly it cannot be rotated. Make sure the rear leading edge is pushed all the way in.
7. At the wing tip, the sail is held in place by a sail tab and a clevis pin that fits through the
leading edge. The sail tab goes to the bottom of the leading edge. Insert the pin through the
grommet and into the bottom hole of the leading edge at an angle. Straighten the clevis pin
while sliding the sail tab towards the leading edge. Ensure the sail tab is not twisted and is
on the bottom of the leading edge. It must not be on the top! Secure pin with safety ring.
