10
3. Clutch Pedal Spring Replacement:
First, remove the cover plate. Then, take out the rear end block of the spring from the slot.
Replace it with the stronger blue spring, reassemble the block in the slot, and put the cover
plate back on.
Installation Method:
Damping Block Hardness (Soft to Hard)
55R 70R 80P 98P
Cylinder cap
Damping blocks
Road Car High-Performance
Car or Supercar
Rally Car GT4 Car GT3 Car F3 Car
Metal washer
R: Rubber P: Polyurethane
Grey Black Yellow Red
4 pcs 4 pcs 8 pcs 8 pcs
To simulate the pedal feel of various race cars, you can freely combine 8 damping blocks as
shown in the diagram. You can use the following recommended combinations or adjust them
according to your preference:
Note：
Do not connect the pedals to both the base and PC simultaneously; connect to only one
device at a time!
