QC
PASS
03
Use a 2.5mm hexagon wrench to turn the screws on the board surface of the pedal
counterclockwise and use a 7mm open-end wrench to remove the nuts on the back and the
screws on the board, move the board up and down to adjust the height of the board
according to your needs, and then fasten the nuts and screws to the board surface. (The
accelerator, brake and clutch are adjusted in the same way)
Instructions for adjusting the pedal board height
04
Packing Details
05
Product Parameters
06
1. SRP pedal
2. Tool kit:
M4*10 socket head countersunk head x12
M8*12 hexagon socket head screw x3
M6*20 socket head cap screws x2
3. Type A to Type B USB cable
Material: high-strength steel
Color: black
Brake sensing method: pressure sensor and angle sensor fusion algorithm
Pressure sensor maximum range: 75kg
Angle sensor resolution: 16 bits
Brake structure: spring + damping block
Throttle sensing method: angle sensor
Clutch sensing method: angle sensor
Pedal spacing:adjustable
Pedal surface height: adjustable
Pedal connection port: USB
Pedal travel software adjustment: yes
Pedal travel reverse function: yes
2.5mm hexagon wrench x1
7mm open end wrench x1
5mm hexagon wrench x1
