Intended Use
The product is intended for use with general ultrasound systems. The product is
intended for the environment where ultrasound systems are used, including
hospitals, outpatient facilities, and doctor’s offices. The product is
contraindicated for patients that cannot safely sit in a chair or lie on an elevated
surface.
WARNING, POTENTIAL FOR INJURY OR DEATH. Do not leave patient
unattended while using the table.
WARNING, POTENTIAL FOR INJURY OR DEATH. Do not modify this
equipment without authorization of the manufacturer.
WARNING, POTENTIAL FOR INJURY OR DEATH. Do not use in oxygen
rich environment.
Set Up
Your UltraScan™ Table has been shipped to you in “plug and play” condition.
After unpacking the product, we recommend performing an initial test of your
UltraScan™ Table to ensure that each function is in correct working order. After
reviewing this manual you are ready to begin using your UltraScan™ Table.
System Test Procedure
The hand-wand is a low voltage, DC operated device. The cable begins at the
hand wand and plugs into the control box.
WARNING, POTENTIAL FOR INJURY OR DEATH. To reduce the risk of
electrical shock, grounding reliability can only be achieved when the
equipment is connected to an equivalent receptacle marked “hospital
only” or “hospital grade”.
STEP
ACTION
1
After removing padding and packaging materials, locate primary
power supply cord and attach to suitable grounded outlet.
2
To test actuator function, locate the hand-wand and depress each
function button one at a time. (Depressing multiple buttons
simultaneously will prevent the motor from operating.) Figure 2.
3
If any function does not operate, perform the test procedures listed
in the Troubleshooting Guide
Isolation from the external electrical supply can be obtained by unplugging the
power cord from the wall outlet or by unplugging the power cord from the control
box.
