PAGE 40 — DCA70SSIU4F 60 HZ GENERATOR DSE8610 MKII • OPERATION MANUAL — REV. #0 (08/11/22)
Additional Engine Operating Parameters
From the main status screen, press the right arrow button
once and verify that the "Engine" screen is displayed
Additional engine parameters such as the ones shown
below can be accessed by pressing the down arrow button
Battery Voltage
Engine Run Time
Engine Inlet Temperature
Engine Fuel Temperature
Engine Turbo Pressure
Engine Fuel Pressure
Engine Percent Torque
Inter-Coolertemperature
Atmospheric Pressure
Electrical Potential
Percent Heat Status
Auxiliary/GFCI Circuit Breakers
1. Place auxiliary and GFCI circuit breakers in the ON
position (Figure 58).
Figure 58. Auxiliary and GFCI
Circuit Breakers (ON)
2. The generator will run until manually stopped or an
abnormal condition occurs.
CIRCUIT
AUX. CIRCUIT
BREAKERS
ON
ON
ON
ON
ON
ON
GENERATOR START-UP PROCEDURE (MANUAL MODE)
