Contents
Indoor Unit Installation ...........15
1. Installation location................................15
2. Attach mounting plate to wall...............16
3. Drill wall hole for connective piping.....16
4. Prepare refrigerant piping ....................18
5. Connect refrigerant piping ....................19
6. Connect drain hose.................................21
7. Wrap piping and cables..........................22
8. Mount indoor unit..................................22
Outdoor Unit Installation ......
23
1. Installation location ............................23
2. Install drain joint .................................24
3. Anchor outdoor unit .......................... 25
5
Refrigerant Piping Connections......................27
Electrical Connections .....................................31
Electrical and Gas Leak Checks.......................33
Test Run.............................................................34
Troubleshooting................................................36
EU Disposal Guidelines.....................................39
