Outdoor Unit Disassembly 15
Procedure Illustration
7) Remove the screws of the right panel
and then remove the right panel
(12 screws) (see CJ_multi_D30-006
and CJ_Multi_D30-007).
CJ_Multi_D30-006
CJ_Multi_D30-007
Note: This section is for reference only. Actual unit appearance may vary.
Right Panel
