Page 6
mrcool.com
Appliance Overview
Fig. 1.1
3
1
1
1
Owner’s Manual
Drain Plug
Drainage Connector
OPTIONAL
No-Vac
®
Quick Connect
®
Lineset
Gas / Liquid
Pipe Assembly
PART LOOKS LIKE... QUANTITY
Unless otherwise stated (as “OPTIONAL”) the air conditioning system includes the following
accessories. Use all of the installation parts and accessories to install the air conditioner.
Improper installation may result in water leakage, electrical shock, fire, or equipment failure.
Owner’s Manual
Universal®™ Series
Central Heating & Air Conditioning
1
1
Liquid Side Stub Kit
Gas Side Stub Kit
To connect the unit
with the liquid pipe
To plug the unused
drain hole
To connect with the
PVC drain pipe
To connect the unit
with the gas pipe
or
To Next Page
