Page 7
mrcool.com
Appliance Overview
COOLING HEATING
Operating Range
5°F (-15°C) ~ 129.2°F (54°C）
Outdoor Temperature
Fig. 1.2
Unit Dimensions of 2-3 Ton Condenser
MDUO18024036
Outdoor Unit Dimensions
Width (A) x Height (C) x Depth (G)
Mounting Dimensions
Width (A / D) Depth (B / E)
37 in x 32-1/4 in x 18-1/8 in.
(940 mm x 820 mm x 460 mm)
37 in / 24 in
(940 mm / 610 mm)
20-7/8 in / 19-1/8 in
(530 mm / 486 mm)
MDUO18024036
-22°F (-30°C) ~ 75.2°F (24°C）
