MSA Alpha Series - 3.10. Removing the Compressed Air Cylinders

MSA USING THE COMPRESSED AIR BREATHING APPARATUS
BD 96 SL 13
GB
3.10. Removing the Compressed Air Cylinders
Fig. 7 Removing the compressed air cylinders
(1) Place the compressed air breathing apparatus in a horizontal position with
the cylinder facing up.
(2) Hinge up tension clamp at cylinder strap and loosen the strap.
(3) Unscrew cylinder valve(s) from pressure reducer and/or T-piece.
Warning!
Do not remove or transport the compressed air cylinder(s) from the
cylinder strap by the handwheel.
This could accidentally open the cylinder valve.
(4) Lift compressed air cylinder(s) at the valve and pull out of the cylinder strap.
(5) Cover high pressure connection and cylinder valve(s) with protective cap(s).
