MSA Ultima Controller User Manual

Settings
Setting Span Values
• Ready
• Send
• Span
• Use +/- for gas list (i.e. 500 ppm CO)
• Enter
• Put in number (i.e. 300)
• Aim
• Enter
Set Date or Time
• Press and hold Date or Time
• Prompt appears
• Put in new date or time
• Enter
Send Date or Time
• Send
• Aim
• Date or Time
Setting Alarm Values
• Ready
• Send
• Alarm
• 0 – set point • 1 – On/O
• Use +/- for gas type • Use +/- for gas type
• Enter • Enter
• Point # • Point #
• Enter • Enter
• Point value • (Alarm prompt) or OR
• Aim • 1 – Enable 0 – Disable
• Enter • Latched / non-latch
Reset Latched Alarms
Send any command and it will reset a latched alarm once it is
below the alarm value.
Send Average Time Interval
• Ready
• Send
• Average
• Use +/- for 1, 8, 24 hours
• Aim
• Enter
Example
• Press and hold ‘PROGRAM’ button until ‘Enter Program #’
• Enter number ‘1 – 9’
• Enter
• Ready
• Hit keystrokes and listen for 2 beeps
• Send
• Display
• + / -
• Previous Cal Date
• Enter (saving)
Programs
You can create Programs 1–9 for repetitive items. (See Manual)
Program Run
• Press ‘PROGRAM’
• Enter #
• Aim
• Enter
Program O
• Repeats last
command
• Press ‘PROGRAM’
• Enter ‘0’
• Aim
• Enter
Clear Programs
• Hold in #0
• Reset Prompt
Yes/No
• Aim
• Press 0 = N, 1 = Y
www.MSAgasdetec tion.com
