• Route this cable with DC power to avoid noise
interference from relay wiring.
b. Connect the two-conductor cable to the two positions of
terminal block J10.
c. Identify the cable to enable proper connection at the button.
d. Route cable to the push-button location; wire the button.
6. Re-install the wiring plugs.
• Ensure that wiring plugs are firmly seated into their mates.
7. Pull the cable away from the unit to relieve any excess
slack.
• It is important not to have excess wire or cable within
the module to avoid unwanted AC noise.
8. Re-install the cover of the Ultima X Series Gas Monitor.
Appendix A, Internal Relay Option
A-12
