01 Swivel eye bolt
02 Tripod head
03 Winch karabiner
04 Winch pulley
05 Workman winch
06 Telescopic legs
07 Tripod feet
08 Tethered leg adjustment bolt
09 Base strap
10 Rescuer pulley
11 Adjustment bolt
12 Hog ring
13 Workman Rescuer SRL-R Class 1
06
07
13
10
08
06
09
06
07
05
02
04
03
01
Tripod terminology
