MSD 6AL-2 User Manual

INSTALLATION INSTRUCTIONS 11
MSD • WWW.MSDPERFORMANCE.COM • (915) 855-7123 • FAX (915) 857-3344
MSD SYSTEMS Installing to an MSD Distributor PN 8360.
INDICATES CONNECTION
•
IGNITION
KEY
TO 12V
ORANGE
WHITE
RED
RED
BLACK
ORANGE
BLACK
TO GROUND
DISTRIBUTOR
PN 8360
RED
MAGNETIC PICKUP
(NOT USED)
+
HEAVY RED
HEAVY BLACK
TO BATTERY
TO BATTERY
+
ORANGE (TO COIL +)
BLACK (TO COIL -)
RED
GREEN (-)
VIOLET (+)
WHITE
BLUE
WHITE/BLUE
HALL-EFFECT
(NOT USED)
2-STEP/LAUNCH
(12V TO ACTIVATE)
GRAY
TACH OUTPUT
MSD SYSTEMS Installing to a Hall-Effect Trigger Distributor.
INDICATES CONNECTION
•
IGNITION
KEY
TO 12V
ORANGE
WHITE/
BLUE
RED
RED
TRIGGER
GROUND
TO GROUND
HALL-EFFECT
12 VOLTS
MAGNETIC PICKUP
(NOT USED)
+
HEAVY RED
HEAVY BLACK
TO BATTERY
TO BATTERY
+
ORANGE (TO COIL +)
BLACK (TO COIL -)
RED
GREEN (-)
VIOLET (+)
WHITE/BLUE
BLUE
WHITE
POINTS/AMPLIFIER
(NOT USED)
2-STEP/LAUNCH
(12V TO ACTIVATE)
GRAY
TACH OUTPUT

MSD 6AL-2 Specifications

General

Ignition Type	Capacitive Discharge
Spark Energy	135 mJ per spark
Operating Voltage	12-18 volts
Weight	3 lbs
Maximum Voltage	18V
Compatibility	For 4, 6, and 8-cylinder engines
