MSI 7C67-001R User Manual

23
Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1, SYS_FAN1~2 Fan Connectors 29
CPU_PWR1, ATX_PWR1 Power Connectors 28
CPU Socket LGA 1151 socket 24
DIMMA1/A2/B1/B2 DIMM Slots 25
JAUD1 Front Audio Connector 31
JBAT1 Clear CMOS Jumper 33
JCI1 Chassis Intrusion Connector 32
JCOM1 Serial Port Connector 31
JFP1, JFP2 Front Panel Connectors 27
JLPT1 Parallel Port Connector 31
JRAINBOW1 Addressable RGB LED connectors 35
JRGB1 RGB LED connector 34
JUSB1~2 USB 2.0 Connectors 30
JUSB3 USB 3.1 Gen1 Connector 30
M2_1 M.2 Slot (Key M) 26
PCI_E1~3 PCIe Expansion Slots 26
SATA1~6 SATA 6Gb/s Connectors 27
